Quick Look
| Density(g/cm³) | Tensile Strength | Young's Modulus | Elongation at Break | Heat Deflection Temperature |
|---|---|---|---|---|
| 1.3 | 40MPa | 2511MPa | 11% | 63℃ |
About the Material
Advantages:
High Precision: High Detail Resin offers excellent dimensional accuracy, perfect for parts with intricate features and fine details.
Smooth Surface Finish: The material provides a smooth surface finish, which is ideal for presentation and visual validation.
Cost-effective: The resin is affordable, making it suitable for creating detailed prototypes and models without significant expenses.
Ease of Post-processing: The resin is easy to sand and finish, allowing for improved surface quality and appearance.
Limitations:
Limited Strength: High Detail Resin is not as strong as other engineering resins, which limits its use for functional or load-bearing parts.
Brittleness: The material can be brittle, making it unsuitable for parts that require high impact resistance.
UV Sensitivity: Parts made with High Detail Resin may degrade over time if exposed to UV light without proper finishing.
Chemical Composition Table for Gray High Detail Resin
| Component | Composition |
| Epoxy-based Resin | Proprietary |
| Photoinitiators | Proprietary |
| Additives | Proprietary |
Mechanical Machining Properties Table for Gray High Detail Resin
| Property | Value |
| Machinability Rating | Moderate |
| Cutting Speed (m/min) | 10~20 |
| Tool Wear Resistance | Moderate |
| Coolant Requirement | Optional |
| Surface Finish Quality | High |
Design Parameters Table for SLA Printing with Gray High Detail Resin
| Maximum Bulid Size（mm） | Minimum Wall Thickness | Minimum Drill Size | Minimum Assembly Gap | Tolerance |
| 800*800*550 | 0.6mm | 0.5mm | 0.2mm | ±0.1% *length(lower limit of ±0.15 mm) |
Industry Applications and Case Studies for SLA Printing with Gray High Detail Resin
Jewelry Industry:
Application: Production of intricate jewelry designs and casting patterns.
Case Study: A jewelry designer used High Detail Resin to create highly detailed prototypes for casting, benefiting from the material's precision and surface finish.
Dental Models:
Application: Manufacturing of dental models for patient treatment planning.
Case Study: A dental lab used High Detail Resin to produce dental models with precise details, enabling accurate patient fittings and treatment planning.
Consumer Goods:
Application: Production of concept models and small components.
Case Study: A consumer goods company used High Detail Resin to create detailed product prototypes for visual validation and ergonomic testing.
Frequently Asked Questions (FAQs) about SLA Printing with Gray High Detail Resin
What are the benefits of using Gray High Detail Resin in 3D printing?
High Detail Resin offers exceptional precision, smooth surface finish, and cost-effectiveness, making it ideal for prototypes and parts with intricate details.
Is Gray High Detail Resin suitable for functional parts?
High Detail Resin is more suitable for visual and presentation purposes rather than functional parts that require high strength or impact resistance.
What industries benefit from SLA printing with Gray High Detail Resin?
Industries such as jewelry, dental, and consumer goods benefit from the properties of High Detail Resin.
How accurate is SLA printing with Gray High Detail Resin?
SLA printing with High Detail Resin can achieve tolerances of ±0.05 mm, suitable for high-precision prototypes and models.
What post-processing is required for Gray High Detail Resin-printed parts?
Post-processing may include sanding, polishing, and UV curing to improve mechanical properties and surface finish.
Can Gray High Detail Resin be used in high-temperature environments?
High Detail Resin has a maximum operating temperature of 50°C, making it suitable for moderate-temperature applications but not for high-heat environments.
How strong are Gray High Detail Resin-printed parts?
High Detail Resin-printed parts are strong enough for visual models and prototypes but may not be suitable for load-bearing or impact-resistant applications.
